Thông tin chi tiết: HiKu7 Mono PERC 645 W ~ 675 W
ELECTRICAL DATA | STC* |
CS7N |
645MS |
650MS |
655MS |
660MS |
665MS |
670MS |
675MS |
Nominal Max. Power (Pmax) |
645 W |
650 W |
655 W |
660 W |
665 W |
670 W |
675 W |
Opt. Operating Voltage (Vmp) |
37.7 V |
37.9 V |
38.1 V |
38.3 V |
38.5 V |
38.7 V |
38.9 V |
Opt. Operating Current (Imp) |
17.11 A |
17.16 A |
17.20 A |
17.24 A |
17.28 A |
17.32 A |
17.36 A |
Open Circuit Voltage (Voc) |
44.8 V |
45.0 V |
45.2 V |
45.4 V |
45.6 V |
45.8 V |
46.0 V |
Short Circuit Current (Isc) |
18.35 A |
18.39 A |
18.43 A |
18.47 A |
18.51 A |
18.55 A |
18.59 A |
Module Efficiency |
20,80% |
20,90% |
21,10% |
21,20% |
21,40% |
21,60% |
21,70% |
Operating Temperature |
-40°C ~ +85°C |
Max. System Voltage |
1500V (IEC/UL)) or 1000V (IEC/UL)) |
Module Fire Performance |
TYPE 1 (UL 61730 1500V) or TYPE 2 (UL 61730 1000V) or CLASS C (IEC 61730) |
Max. Series Fuse Rating |
30 A |
Application Classification |
Class A |
Power Tolerance |
0 ~ + 10 W |
* Under Standard Test Conditions (STC) of irradiance of 1000 W/m2, spectrum AM 1.5 and cell temperature of25°C. |
ELECTRICAL DATA | NMOT* |
CS7N |
645MS |
650MS |
655MS |
660MS |
665MS |
670MS |
675MS |
Nominal Max. Power (Pmax) |
484 W |
487 W |
491 W |
495 W |
499 W |
502 W |
506 W |
Opt. Operating Voltage (Vmp) |
35.3 V |
35.5 V |
35.7 V |
35.9 V |
36.1 V |
36.3 V |
36.5 V |
Opt. Operating Current (Imp) |
13.72 A |
13.74 A |
13.76 A |
13.79 A |
13.83 A |
13.85 A |
13.88 A |
Open Circuit Voltage (Voc) |
42.3 V |
42.5 V |
42.7 V |
42.9 V |
43.1 V |
43.3 V |
43.5 V |
Short Circuit Current (Isc) |
14.80 A |
14.83 A |
14.86 A |
14.89 A |
14.93 A |
14.96 A |
14.99 A |
* Under Nominal Module Operating Temperature (NMOT), irradiance of 800 W/m2, spectrum AM 1.5, ambienttemperature 20°C, wind speed 1 m/s. |
